Notice:
1.Need to buy DC 24V transformer additionally! (Unless you have it already) 2.The total wattage of light strip is suggested less than 80% rated wattage of transformer, lest influence the lifespan of transformer. 3.For example, 1×4M 9.5W/M Skyline linear lights, its light strip wattage is total 38W. Need to equip with the transformer over 47.5W at least. Therefore, we suggest you choose the 60W transformer is OK. Computational formula: (1). 1(pieces)×4(length)×9.5(each meter light strip's wattage)=38W 38÷0.8=47.5W→Choose 60W Transformer (2). 1(pieces)×4(length)×10(each meter light strip's wattage)=40W 40÷0.8=50W→Choose 60W Transformer
Purchase advice:
1. 10W/M COB light strip is more suitable for emitting light downward, because COB light strip won't emit the dazzling light into your eye. And it has cover for light strip. 2. Normal 9.5W/M light strip is more suitable for emitting light upward. Because its light won't emitting into your eyes directly when they emit light upward. 3.You won't see many difference between the normal type and COB type when you watch them at a far position. But when you near to the product(Lights ON), and watch through them carefully, then you will find the COB type get much less granular sensation than the normal one.
Product Advantages:
Brand: MR.XRZ Material: Die-cast Aluminum Light source type: LED CRI (Color Rendering index (Ra>90) close to daily vision, which is eye-protecting and more suitable for reading) Light Strip Chips Brand: Bridgelux Transformer Brand: DC 24V OSRAM Transformer Input Voltage: AC 220V-240V (If your country is other voltage, please contact us. We can change other transformer for you.) Output Voltage: DC 24V Wattage: 9.5W/M, 10W/M (COB) Luminous Flux: 1115 lm/m Beam angle: 120 degrees Color temperature: Warm White (3000K), Natural white (4000K) Warranty period: 2 years Life hours: 50,000 hours
Package Kit List:
1×4m/8m 9.5W/M or 10W/M(COB) Light Strips 1×4m/8m Steel Strips 1×Connection Base and Its Accessories 1×Engineering Scissor Need to buy additionally: 1×60W/120W/180W DC 24V OSRAM Transformer (Unless you have it already!) Please add all the neccessary parts (Skyline Linear Lights and OSRAM Transformer) you need to your "Cart", then place an order together!
Shipping:
1. Worldwide shipping method. (Except some countries and APO/FPO) Standard shipping: AliExpress Standard Shipping (Free shipping, usually take 60-90 days). Fast shipping: Most countries via DHL, FedEx, UPS (usually takes 4-8 days), Russian Federation via EMS (usually takes 17-30 days) or AliExpress Premium Shipping (usually takes 18-35 days); Due to the Russian customs policy, we can't send personal parcels to Russian Federation via DHL, FedEx, UPS, etc.; 2. We will send out the order as soon as possible, usually 2-7 days. 3. The logistic tracking information usually will updates within 4-10 days, if there are any problem, please contact us.
Installation procedure
Surface Mounted Type Installation procedure 1.Certain the installation position, reserve space for the 24V transformer Before installation, reserve the space for transformer 2.Connect the 24V transformer with the wire, fix the non-wire base Do the same way to fix another the non-wire base 3.Cut the steel strip according to the distance The distance to the base The cut length of steel strip is 195mm shorter than wall distance 4.Attach the light strip into the steel strip When attaching the light strip, leave extra 65mm for the steel strip fixation. 5.Fix and adjust the steel strip 6.Connect the wire box, lid the board, finish the installation Rimless Recessed Type Installation procedure 1.Certain the installation position, reserve space for the 24V transformer Before installation, reserve the space for transformer 2.Groove the wall, check the groove size 3..Connect the 24V transformer with the wire, fix the non-wire base Do the same way to fix another the non-wire base 4.Cut the steel strip according to the distance The distance to the base The cut length of steel strip is 145mm shorter than wall distance 5.Cut the light strip according to the distance When attaching the light strip, leave extra 65mm for the steel strip fixation. 6.Fix and adjust the steel strip 7.Connect the wire box, lid the board, finish the installation 8.Plaster the putty and paint, installation complete
